Quick Change - Holemaking Tools - Spade Drills

Quick Change - Holemaking Tools
QSD | Turning Tools

Designed for drilling in hardened materials, Micro 100s' QSD line of solid carbide spade drills is an excellent option when requiring holes free of retrack marks in non-ferrous materials.

  • Designed for drilling in hardened materials
  • Excellent option when requiring holes free of retrack marks in non-ferrous materials
  • Coolant fed enabled shank design
  • Proprietary Micro-Quik™ quick change system maximizes productivity through reliable accuracy and locational repeatability
  • Point geometry designed for self-centering
  • 118° tip angle

Advanced Search

Drill Diameter Web Thickness Length From Holder Shank Diameter Overall Length Uncoated AlTiN Coated Add to Cart Default Sort
D1 +.0000"
-.0005
T +.001"
-.001"
L4 D2 (h6) L1 Tool # Price Tool # Price
.0312 .010 .340 .1875 1.25 QSD-031 $16.40 QSD-031X $18.30 00000001
.0625 .012 .590 .1875 1.50 QSD-062 $17.05 QSD-062X $18.95 00000002
.0938 .016 .590 .1875 1.50 QSD-093 $17.50 QSD-093X $19.40 00000003
.1250 .020 .590 .1875 1.50 QSD-125 $19.25 QSD-125X $21.15 00000004
.1562 .025 1.090 .1875 2.00 QSD-156 $21.00 QSD-156X $22.90 00000005
.1875 .028 1.090 .1875 2.00 QSD-187 $24.45 QSD-187X $26.35 00000006
.2500 .035 .853 .2500 2.00 QSD-250 $32.90 QSD-250X $34.80 00000007
.3125 .040 1.353 .3125 2.50 QSD-312 $45.50 QSD-312X $47.40 00000008
.3750 .046 1.353 .3750 2.50 QSD-375 $54.85 QSD-375X $56.75 00000009
